The CL-204 capacitive oil level sensor is a high-precision, durable industrial level detection device independently developed for oil medium monitoring. Adopting advanced capacitive sensing technology and integrated dedicated measurement chips, this sensor realizes non-contact, continuous and linear detection of oil level changes. Different from traditional mechanical float sensors, it has no mechanical moving parts, effectively avoiding wear, jamming and failure problems during long-term operation. Designed for harsh industrial working environments, the CL-204 sensor features strong anti-interference ability, stable signal output and wide temperature adaptability. It supports both standard batch supply and personalized customized services, fully meeting the diversified oil level monitoring demands of mechanical equipment, automated production lines and industrial supporting facilities, and is a reliable choice for industrial oil tank real-time monitoring and intelligent liquid level control.
Product Features
High Precision & Stable Detection Performance
Equipped with a high-precision capacitive measurement chip and built-in temperature compensation and linear correction algorithms, the sensor effectively eliminates detection errors caused by ambient temperature changes and oil medium dielectric fluctuation. It delivers highly linear and repeatable oil level detection data, ensuring long-term stable and accurate monitoring results without signal drift.
No Mechanical Wear & Long Service Life
Adopting fully electronic non-contact detection structure with no floating balls, connecting rods or other mechanical moving parts. It avoids mechanical fatigue, jamming, abrasion and corrosion failure caused by frequent liquid level fluctuation, greatly reducing later maintenance frequency and replacement cost, and adapting to 24-hour continuous industrial operation.
Strong Environmental Adaptability & Anti-Interference Ability
The whole machine adopts sealed industrial-grade protection design, with excellent dustproof, waterproof and anti-corrosion performance. It can resist electromagnetic interference, vibration and oil medium erosion in complex industrial environments, stably operate in high and low temperature working conditions, and is suitable for various harsh factory and equipment operation scenarios.
Wide Compatibility & Easy Integration
Supports standard universal signal output, which can be perfectly matched with industrial PLC, controller, display instrument and automatic control system. It is compatible with various lubricating oil, hydraulic oil, gear oil and other industrial oil media, with strong versatility, and can be quickly integrated into new and old mechanical and automation equipment systems.
Working Principle
The CL-204 capacitive oil level sensor operates based on the parallel plate capacitance detection principle. The sensor probe acts as the main electrode, and the metal tank wall or built-in reference electrode forms the auxiliary electrode, with the oil and air between the two electrodes serving as the dielectric medium. Since the dielectric constant of industrial oil is much higher than that of air, when the oil level rises or falls, the proportion of oil and air in the sensor detection electric field changes synchronously, resulting in a linear change in the overall capacitance value of the sensor. The built-in high-precision chip captures tiny capacitance changes in real time, converts the capacitance variation corresponding to oil level height into standard analog or digital electrical signals, and outputs stable and readable level data, realizing real-time, continuous and accurate monitoring of oil level.
Product Parameters
|
Parameter Item |
Technical Specification |
|
Product Model |
CL-204 |
|
Detection Principle |
Capacitive Induction |
|
Measuring Range |
50mm - 2000mm (customizable) |
|
Detection Accuracy |
±0.5% FS |
|
Repeatability |
≤0.2% FS |
|
Output Signal |
4-20mA / 0-10V / RS485 (optional) |
|
Working Voltage |
DC 12V - 24V |
|
Working Temperature |
-40℃ ~ +85℃ |
|
Protection Grade |
IP67 |
|
Shell Material |
Stainless Steel 304/316 |
|
Applicable Media |
Hydraulic Oil, Lubricating Oil, Gear Oil, Diesel Oil and other non-conductive oil |
|
Response Time |
≤100ms |
Application Fields
The CL-204 capacitive oil level sensor is professionally designed for industrial oil level monitoring, widely applicable to mechanical equipment and automation equipment scenarios. In mechanical equipment, it is suitable for engineering machinery, machine tools, compressors, hydraulic stations, diesel generators and other equipment oil tank level monitoring, realizing real-time detection of lubricating oil and hydraulic oil reserves. In automation equipment, it matches automated production lines, intelligent processing equipment, industrial robot supporting systems and automated fluid supply equipment, providing accurate oil level data support for automatic oil supply, low-level alarm and equipment fault early warning, ensuring the stable and safe operation of industrial equipment.
Installation Method
The CL-204 sensor supports multiple flexible installation methods to adapt to different tank structures and equipment layouts. The mainstream installation is top thread installation: fix the sensor on the top opening of the oil tank through standard thread interface, with the probe vertically inserted into the oil tank, featuring simple operation, good sealing and no leakage risk. It also supportsside flange installation and custom bracket fixing for special tank body structures. During installation, ensure the probe is kept vertical and away from the tank wall and internal baffles to avoid detection interference. The whole installation process is convenient and fast, no need to modify the equipment structure in a large scale, and it can be quickly put into use after wiring and debugging.
Customizable Options
We support full-dimensional personalized customization to meet customers' unique on-site working conditions and equipment matching needs:
Size Customization
Customize probe length, sensor overall size and thread specification according to customer oil tank depth and installation space;
Signal Customization
Customize special output signals, signal range and communication protocols to match customers' exclusive control systems;
Material & Protection Customization
Upgrade shell anti-corrosion materials, enhance protection grade, and customize high-temperature and explosion-proof versions for special harsh environments;
Function Customization
Add high/low oil level alarm, data storage, remote transmission and other extended functions as required.
Why Choose Us
Superior Product Performance & High Cost Performance
Adopting core capacitive sensing technology, with high precision, strong stability and long service life, it avoids frequent replacement and maintenance of traditional sensors, effectively reducing customers' long-term operating costs, and has obvious cost performance advantages in industrial long-term application.
Full-scenario Customized Service
We have mature customization experience for mechanical and automation equipment industries, can accurately match various industrial oil level monitoring scenarios, provide exclusive customized solutions for customers' special working conditions, and solve personalized detection pain points.
Reliable Quality & Stable Supply
Standardized production process and strict quality inspection system ensure stable product quality. With sufficient production capacity and perfect supply chain system, we can support long-term batch orders and urgent order delivery to meet customers' production and delivery schedules.
Professional After-sales Technical Support
We provide one-stop services including pre-sales scheme design, in-sales technical guidance and after-sales installation debugging and maintenance support. The professional technical team responds quickly to solve customers' on-site use problems, ensuring worry-free product use.
FAQ
Q: What types of oil media is the CL-204 sensor suitable for?
A: It is mainly applicable to non-conductive industrial oil media, including hydraulic oil, lubricating oil, gear oil, diesel oil and other conventional industrial oils, which can meet the oil level monitoring needs of most mechanical and automation equipment.
Q: Can the sensor work stably in high and low temperature environments?
A: Yes. The working temperature range of the sensor is -40℃ to +85℃, with built-in temperature compensation function, which can effectively resist temperature interference and maintain accurate and stable detection data in high temperature, low temperature and temperature alternating environments.
Q: Is it difficult to install and debug the sensor?
A: The installation is simple and fast, with standard thread and flange interface. It can be installed and used after simple wiring and signal debugging. We will provide detailed installation manuals and technical guidance to support customers' independent installation and commissioning.
Q: Can non-standard size and function customization be realized?
A: Yes. We support full-range customization of probe length, installation interface, output signal, protection performance and extended functions, and can provide exclusive customized solutions according to customers' actual equipment and working condition requirements.
Q: What is the service life of the sensor?
A: The sensor has no mechanical moving parts, with zero wear during operation. The industrial-grade sealed structure and high-quality materials ensure a long service life, which can reach more than 5 years under normal industrial working conditions, with low failure rate and high stability.
