The FH-507 ultrasonic meters natural gas is a professional non-intrusive gas flow measurement device independently developed for natural gas and conventional gas medium detection. Tailored for HVAC, heating, and air conditioning system scenarios, this ultrasonic natural gas flow meter adopts advanced transit-time ultrasonic measurement technology, delivering high-precision, zero-pressure-loss gas flow monitoring performance. Different from traditional mechanical gas meters, the FH-507 features no internal moving parts, no wear and tear, and extremely low maintenance costs, ensuring long-term stable operation in heating and central air-conditioning gas supply systems. It supports real-time monitoring of natural gas instantaneous flow and cumulative consumption, adapts to variable gas pressure and flow fluctuations in HVAC systems, and offers both standard finished products and customized solutions to meet diverse on-site pipeline and working condition requirements.
Product Features
Zero Pressure Loss & No Mechanical Wear
The FH-507 ultrasonic meters natural gas adopts non-contact external measurement structure with no internal movable components. It causes no pipeline pressure drop during natural gas measurement, avoids gas energy loss, and eliminates mechanical wear, greatly extending the service life and reducing daily maintenance frequency for HVAC and heating systems.
High Precision & Wide Turndown Ratio
Equipped with high-sensitivity dedicated gas ultrasonic probes and intelligent signal processing algorithms, the meter achieves measurement accuracy up to ±0.8%. It stably captures low-flow and fluctuating natural gas flow in heating and air conditioning pipelines, with a wide turndown ratio to adapt to variable gas consumption in different seasonal and operational scenarios.
Strong Environmental Adaptability for HVAC Scenarios
Designed for long-term operation in indoor and outdoor heating, ventilation and air conditioning environments, it resists temperature changes, slight dust and conventional electromagnetic interference. It maintains consistent measurement stability in boiler gas supply, central air-conditioning energy-saving monitoring and community heating gas pipeline systems.
Intelligent Data Monitoring & Easy Management
Supports real-time display of natural gas instantaneous flow, total cumulative flow, gas velocity and operating status. It comes with automatic data logging and data export functions, facilitating energy consumption statistics, HVAC system energy efficiency analysis and daily gas consumption management for enterprises.
Working Principle
The FH-507 ultrasonic meters natural gas operates based on the gas ultrasonic transit-time difference principle, complying with international AGA #9 and GB/T18604 industry standards. A pair of ultrasonic transducers are installed on the outer wall of the natural gas pipeline, alternately transmitting and receiving ultrasonic signals that penetrate the gas medium. When natural gas is static, the upstream and downstream signal propagation time is equal. When gas flows, the ultrasonic signal traveling with the gas flow has a shorter transit time, while the counter-flow signal takes longer. The built-in high-speed microprocessor accurately calculates gas flow velocity and instantaneous flow by capturing the precise time difference, and accumulates total gas consumption. Combined with temperature and pressure compensation algorithms, it realizes accurate and stable natural gas flow measurement for HVAC and heating systems.
Product Parameters
|
Parameter Item |
Technical Specification |
|
Product Model |
FH-507 |
|
Core Application |
Natural gas measurement for HVAC, heating and air conditioning systems |
|
Measurement Principle |
Transit-time ultrasonic difference method with temperature & pressure compensation |
|
Measurement Accuracy |
±0.8% (standard working condition) |
|
Pipe Diameter Range |
DN25mm – DN2000mm |
|
Applicable Medium |
Pure natural gas, conventional town gas, low-impurity combustible gas |
|
Working Pressure Range |
0.1MPa – 4.0MPa |
|
Working Temperature |
-30℃ ~ +85℃ |
|
Display Mode |
Backlight LCD digital display (flow rate, total volume, temperature, pressure) |
|
Data Interface |
RS485/RS232, support remote data transmission and export |
|
Protection Grade |
IP67 |
|
Service Life |
More than 10 years (no wearing parts) |
Application Fields
The FH-507 ultrasonic meters natural gas is professionally optimized for HVAC, heating and air conditioning industries, covering all scenarios requiring precise natural gas flow monitoring and energy consumption statistics. Typical applications include commercial building central air-conditioning gas supply detection, industrial factory heating boiler natural gas metering, community central heating pipeline gas flow monitoring, HVAC system energy-saving transformation and gas consumption audit, shopping mall and hotel heating & ventilation gas measurement, as well as daily operation monitoring and energy efficiency evaluation of gas-fired air conditioning and heating equipment. It provides accurate data support for energy management and cost control of HVAC and heating systems.
Installation Method
This ultrasonic natural gas flow meter adopts a convenient external clamp-on non-intrusive installation, requiring no pipeline cutting, drilling or system shutdown, which will not affect the normal operation of HVAC and heating systems. First, select a straight and intact pipe section (avoid elbows, tees, valves and deformed pipe sections) that meets the front and rear straight pipe distance requirements, and clean the pipeline surface thoroughly to remove dust, rust and paint. Then install and fix the two matched ultrasonic sensors on the pipe outer wall according to the standard spacing, and apply special high-temperature coupling agent to ensure tight fitting and stable signal transmission. Finally, power on the host, set parameters such as pipe diameter, pipe material and gas medium, and the meter can complete debugging and start real-time measurement within 5 minutes. The whole process is simple, efficient and free of professional construction.
Customizable Options
As a professional sensor manufacturer, we provide diversified personalized customization services for FH-507 ultrasonic meters natural gas to adapt to different HVAC and heating working conditions:
1. Hardware Customization
Customize high and low temperature resistant sensors, anti-corrosion and dust-proof probes, extended signal lines, and explosion-proof models for special heating workshops and outdoor exposed pipelines.
2. Functional Customization
Customize high-precision enhanced modules for low-flow gas measurement, independent temperature and pressure compensation modules, and over-limit alarm functions for abnormal gas flow and pressure.
3. System Customization
Support multi-language interface switching, customized data transmission protocols, cloud remote monitoring access, and automatic energy consumption report generation to match enterprise intelligent HVAC management systems.
Why Choose Us
Professional HVAC & Heating Scenario Optimization: Different from general gas flow meters, the FH-507 is specially optimized for natural gas consumption characteristics of heating, ventilation and air conditioning systems, with stronger anti-fluctuation ability and higher scenario matching degree.
Zero Maintenance & Low Operation Cost: No internal mechanical wearing parts, no blockage failure, no regular maintenance and calibration required. It effectively reduces the later operation and maintenance costs of enterprise HVAC energy management systems.
Flexible Customization & Cost-Effective: As a direct manufacturer, we offer transparent and competitive prices for standard products. We support targeted customization according to on-site pipeline conditions and functional demands, providing high-cost-performance exclusive solutions.
Reliable Quality & Worry-Free After-sales: Adhering to strict quality control standards, the product has low failure rate and long service life. We provide long-term warranty, free technical guidance, installation debugging and remote after-sales support.
FAQ
Q: What scenarios is the FH-507 ultrasonic meters natural gas suitable for?
A: It is specially designed for natural gas flow measurement in HVAC, heating and air conditioning fields, widely used in boiler heating, central air conditioning gas supply, commercial building heating and other scenarios, and also applicable to conventional industrial natural gas pipeline metering.
Q: Does the installation require cutting the natural gas pipeline?
A: No pipe cutting or drilling is required. The clamp-on external installation realizes completely non-destructive measurement, without stopping gas supply or affecting the normal operation of HVAC and heating systems.
Q: Can this meter adapt to fluctuating natural gas flow in heating systems?
A: Yes. The FH-507 adopts an intelligent anti-interference algorithm and wide turndown ratio design, which can stably and accurately measure natural gas flow with frequent flow and pressure fluctuations in seasonal heating and variable-load air conditioning systems.
Q: Is regular maintenance needed during long-term use?
A: Basically no daily maintenance is required. Without internal wearing parts, the meter avoids wear failure and blockage problems. Only regular cleaning of the sensor surface is needed to ensure stable signal transmission.
Q: Do you support OEM/ODM customization for HVAC engineering projects?
A: Yes. We provide full-range customization services including product hardware, functions, software system and logo OEM, supporting batch customized supply for large HVAC and heating engineering projects.
